>> RFID Reader>> Handheld mobile computer

c5000

"ALL IN ONE" Design!! More Rugged with Higher Industrial Standard.

C5000 for uhf,hf,lf reader/writer
c500 reader
Parameters of C5000:
Dimensions: 186.5*75*38.9 mm
Weight: < 300 g (with battery)
Screen: 3.2" QVGA backlight TFT-LCD, 65 K colors. 240 x 320 (QVGA size)
Touch panel: glass analog resistive touch, transparent type, semi-transparent type (optional)
Backlight: LED backlight
Battery: rechargeable li-ion polymer battery (3.7 V/4,000 mAh)
Expansion slots: SIM/SAM, Micro SD (TF) card
Indicator: LED
Input method: touch input and keyboard input
Audio: 0.5 watt
Operating system:
Windows Embedded CE 6.0 Core
CPU: Samsung ARM920T@533 MHz
Memory: 128 MB RAM/1 GB Flash
Expansion Memory:
4G TF (standard), maximum 32G
Interfaces: USB 2.0; RS232
Environmental:
Operating temperature: -20 C ~ 50 C
Storage temperature: -25 C ~ 70 C
Humidity: 5% RH ~ 95% RH (non-condensing)
Dropping survive: 1.5-meter drop test on six sides (concrete floor, under operating temp)
Rolling survive: 1,000 times, 0.5 meter, rolling by six contact surfaces
Environmental sealing: IP64

RFID:
Operating frequency: 125 KHz, 134.2 KHz, 13.56MHz, 840~960 MHz
Protocol: ISO18000-2, ISO11784, ISO11785, ISO14443A/B, ISO15693, ISO18000-6C, EPC C1 GEN2
Other option:
WIFI: IEEE802.11 b/g, GPRS:GSM/GPRS (850,900,1800,1900MHz) 85.61/42.8bps; Bluetooth: Class 2.0+EDR, 3~5 m
1D Linear Scanner (Optional), 2D Imager Scanner (Optional)
